제품 목록
Photo Model Standard Catalogue
SIRO Measurement ranges:
CO2: 0-2000 ppm / 400-2000 ppm
(selectable via jumper)
VOC: CO₂eq: 400-2000 ppm
TVOC ppm: 0-30.0 ppm
TVOC ?g/m3: 0-10000 μg/m3
IAQ index: 1-5 (UBA rating)
PM1/PM2.5/PM10: 0-50 μg/m³ / 0-500 μg/m³
(selectable via jumper)
IAQ index: 1-5 (WHO rating)
Temperature: 0-50 °C
Relative humidity: 0-100 %rH

Outputs:
4 outputs, have to select voltage or current
Voltage outputs: 0-10 V
2-10 V / 0-5 V (optional, display or configuration tool (required)
Current output: 4-20 mA (optional)

 PDF 다운로드
SIRO-MOD Measurement ranges:
CO2: 0-2000 ppm / 400-2000 ppm
(selectable via jumper)
VOC: CO₂eq: 400-2000 ppm
TVOC ppm: 0-30.0 ppm
TVOC ?g/m3: 0-10000 μg/m3
IAQ index: 1-5 (UBA rating)
PM1/PM2.5/PM10: 0-50 μg/m³ / 0-500 μg/m³
(selectable via jumper)
IAQ index: 1-5 (WHO rating)
Temperature: 0-50 °C
Relative humidity: 0-100 %rH

Protocol: MODBUS over Serial Line
Transmission Mode: RTU
Interface: RS485
Byte format 11 bits (10 bits if parity none):
Coding System: 8-bit binary
Bits per Byte:
1 start bit
8 data bits, least significant bit sent first
1 bit for parity
1 stop bit
Baud rate: selectable in configuration
Modbus address: 1?247 addresses selectable in configuration menu
 PDF 다운로드
AM100 측정 범위 :
PM2.5: 0~1,000 μg/m3 PM10: 0~1,000 μg/m3
일산화탄소: 0~100 ppm
이산화질소: 0~5 ppm
오존센서: 0~1000 ppb
온도: -40℃~80℃ / 습도: 0~99%RH
자외선지수: 0~15 UVI(290 ~ 390 nm) 		PDF 다운로드
TFA Series (외기용) 측정 범위 :
PM2.5: 0~1,000 μg/m3 PM10: 0~3,000 μg/m3 TSP: 0~5,000 μg/m3
온도: -20℃~60℃ / 습도: 0~99%RH
CO2 0～2,000ppm
TVOC 0~3.5 mg/m3 		PDF 다운로드
MSD IAQ (실내용) 측정 범위 :
PM2.5: 0~1,000 μg/m3 PM10: 0~1,000 μg/m3
온도: 0℃~50℃ / 습도: 0~99%RH
CO2 0～5,000ppm
TVOC 0~2.0 mg/m3 		PDF 다운로드
