가스 측정 및 시험장비

HOME > 제품소개 > 가스 측정 및 시험장비
제품 목록
Photo Model Standard Catalogue
BPM-200 Principle : Beta ray attenuation (베타선 흡수법)
Resolution : 1 μg/m3
Lower Detectable Limit : 5 μg/m3
Reproducibility : < 7%
Range : 1 mg/m3 to 10 mg/m3 Selectable
PDF 다운로드
AQMS-3000 Parameter : SO , NO , CO, Ozone, PM10, PM2.5, Temp, RH, Wind

( PM Module )
Principle: Light Scattering (광산란법)
Range: 0~10 mg/m3
Accuracy: ± 10%

( Gas Module )
Principle: Electro-Chemical
Range: 0~500 ppb, CO:0~50 ppm
Time Resolution: 1 min
Detectable Limit: 5 ppb, CO:0.04 ppm
PDF 다운로드
CDMS-1000 Particulates : TSP, PM2.5, PM10
Principle : Light scattering (광산란법) (Auto-calibration)
Range : 0-100 mg/m3
Resolution : 1 ㎍/m3
Accuracy : ±10%
PDF 다운로드
AMMS-100 [ Specification : Metal ]
Method of Detection : XRF (USEPA Method IO 3.3)
Range : 0-100 μg/ m3
Detection Limit : 0.01-1ng/m3 with 240 mins sampling and analysis time, 16.7L/min flow rate
Repeatability : < 1.5% (Pb calibration standard<5μg/cm2)

[ Specification : PM ]
Method of Detection : Beta-ray Attenuation (광산란법)
Range : 0-200/0-500/0-1000/0-5000 μg/m3
Detection Limit : 2 μg/m3
Repeatability : < 2% (against reference foil value)
PDF 다운로드
FH62C14 측정방법 : 베타선 흡수법(광원:C14)
측정범위 : 0~5000μg/㎥ or 0~10000μg/㎥
최저측정한계 : 1μg/㎥이하
영점편차 : ±1% 이하
스팬편차 : ±1% 이내
PDF 다운로드
